Professional Stepper Motor in driving techonoly

Our main products includes stepper motors, closed loop system, linear stepper motor, brake stepper motor, stepper drivers, controller board, spindles, power supplys, and other accessories. Pls check our data and hope it is helpful to you. It is supported to customize as requirement.

42BYG Specification
Model	Poles	Voltage	Current	Resistance		Max Static Torque	Cogging Torque	Weight
		V	A	Ω	mH	g.cm	g.cm	KG
42BYG006	2	12	0.8	15	19	1600	<200	0.2
42BYG008	4	32	0.38	17	13,7	800	<150	0.2
42BYG008G	2	32	0.32	13.7	22.2	900	<150	0.2
42BYG009	2	22	0.6	7	6	1400	<180	0.2
42BYG012	2	24	0.52	9	11	1700	<220	0.2
42BYG014	4	8.4	0.45	19	13	1350	<200	0.2
42BYG015	4	12	0.3	40	19	1250	<200	0.2
42BYG016	4	24	0.32	75	55	1600	<200	0.2
42BYG017	2	27	0.42	15	16	1400	<180	0.2
42BYG020	4	12	0.6	20	14	1700	<200	0.2
42BYG023	2	12	0.4	30	36	2100	<220	0.2
42BYG025	2	24	0.8	21	2	1000	<200	0.2
42BYG026	4	9.6	0.4	24	13	1100	<200	0.2
42BYG205	4	9.6	0.48	20	15	1300	<220	0.24
42BYG228	4	12	0.4	30	23	2000	<220	0.24
