| NEMA 42(110MM) | |
| Product name | NEMA 42(110MM) |
| Steppermotor's Poles | 2 ; 4 |
| Frame Size | 110mm*110mm |
| Voltage | 1-220V |
| Max Static Torque | 10-30N.cm |
| Resistance | 0.5-5Ω |
| Weight | 5kgs-12kgs |
| Color | black |
| Application | Centrifugal machinery |
| Sewage treatment machine | |
| spotlight | |
| CNC machine tool | |
| Automatic feeding | |
| Feeder | |
| Wire cutting the workbench, | |
| Planting machine table (pores positioning) | |
| Packing machine | |
| ATM machine, | |
| Inkjet printer, | |
| Cutting plotter, | |
| Spraying equipment, | |
| Medical equipment and equipment, | |
| precision instrument, | |
| Industrial control system, | |
| office automation, |
|
Model 型号 |
Lead Wire 引出线 |
Length 机身长 |
Current 电流 |
Resistance 电阻 |
Inductance 电感 |
Max Static Torque 静转矩 |
Rotor Inertia 转子惯量 |
Weight 重量 |
| No. | mm | A | Ω | mH | N.cm | g.com2 | KG | |
| 110BYGH99-01A | 4 | 99 | 5.5 | 0.9 | 12.0 | 11.0 | 5500 | 5.00 |
| 110BYGH150-01A | 4 | 150 | 6.8 | 0.8 | 15.0 | 21.0 | 10900 | 8.40 |
| 110BYGH165-01A | 4 | 165 | 6.0 | 0.8 | 14.0 | 24.0 | 12500 | 9.50 |
| 110BYGH201-01A | 4 | 201 | 8.0 | 0.7 | 12.0 | 28.0 | 16200 | 11.70 |
