| NEMA 34(86MM) | |
| Product name | NEMA 34 (86MM) |
| Steppermotor's Poles | 2 ; 4 |
| Frame Size | 86mm*86mm |
| Voltage | 2.0V-7.4V |
| Max Static Torque | 2200-9000 g.cm |
| Resistance | 0.42-22Ω |
| Weight | 1.7kgs-5kgs |
| Color | black |
| Application | Centrifugal machinery |
| Sewage treatment machine | |
| spotlight | |
| CNC machine tool | |
| Automatic feeding | |
| printer | |
| Feeder | |
| Wire cutting the workbench, | |
| Planting machine table (pores positioning) | |
| Packing machine | |
| ATM machine, | |
| Inkjet printer, | |
| Cutting plotter, | |
| Photo machine, | |
| Spraying equipment, | |
| Medical equipment and equipment, | |
| Computer peripherals and mass storage devices, | |
| precision instrument, | |
| Industrial control system, | |
| office automation, | |
| Robots and other fields. | |
| Computer embroidery machine, etc. |
|
Model 型号 |
Lead Wire 引出线 |
Length 机身长 |
Current 电流 |
Resistance 电阻 |
Inductance 电感 |
Max Static Torque 静转矩 |
Rotor Inertia 转子惯量 |
Weight 重量 |
| No. | mm | A | Ω | mH | kg.cm | g.com2 | KG | |
| 86BYGH68-01A | 4 | 68 | 4.0 | 0.6 | 3.2 | 2.6 | 850 | 2.00 |
| 86BYGH73-01A | 2 | 73 | 4.2 | 0.5 | 3.5 | 30 | 1050 | 1.7 |
| 86BYGH73-02A | 4 | 73 | 2 | 22 | 7.7 | 22 | 1050 | 1.7 |
| 86BYGH73-03A | 4 | 73 | 3 | 1 | 3.5 | 22 | 1050 | 1.7 |
| 86BYGH73-04A | 4 | 73 | 4.5 | 0.5 | 1.5 | 22 | 1050 | 1.7 |
| 86BYGH80-01A | 4 | 75 | 6.0 | 0.4 | 3.5 | 4.5 | 1050 | 2.50 |
| 86BYGH98-01A | 4 | 98 | 5.0 | 0.5 | 4.0 | 6.8 | 1550 | 3.00 |
| 86BYGH113-01A | 2 | 113 | 4.5 | 0.75 | 6 | 60 | 1800 | 2.8 |
| 86BYGH113-02A | 4 | 113 | 2 | 3.2 | 14 | 44 | 1800 | 2.8 |
| 86BYGH113-03A | 4 | 113 | 3 | 1.5 | 6 | 44 | 1800 | 2.8 |
| 86BYGH113-04A | 4 | 113 | 4.5 | 0.66 | 2.5 | 44 | 1800 | 2.8 |
| 86BYGH116-01A | 4 | 114 | 6.0 | 0.6 | 6.8 | 8.5 | 1800 | 3.50 |
| 86BYGH128-01A | 4 | 128 | 5.0 | 0.6 | 5.0 | 9.0 | 2200 | 3.90 |
| 86BYGH153-01A | 2 | 153 | 5.6 | 0.49 | 4.2 | 90 | 2500 | 3.8 |
| 86BYGH153-02A | 4 | 153 | 2 | 3.8 | 19 | 66 | 2500 | 3.8 |
| 86BYGH153-03A | 4 | 153 | 4 | 0.97 | 4.2 | 66 | 2500 | 3.8 |
| 86BYGH153-04A | 4 | 153 | 6 | 0.42 | 1.7 | 66 | 2500 | 3.8 |
| 86BYGH155-01A | 4 | 155 | 6.0 | 0.8 | 8.5 | 11.0 | 2500 | 4.20 |
