| NEMA 23(57MM) | |
| Product name | NEMA 23(57MM) |
| Steppermotor's Poles | 2 ; 4 |
| Frame Size | 57mm*57mm |
| Voltage | 1.3V-8.6V |
| Max Static Torque | 1000-2500 g.cm |
| Resistance | 0.3-8.6Ω |
| Weight | 0.5kgs-2.0kgs |
| Color | black |
| Application | Centrifugal machinery |
| Sewage treatment machine | |
| spotlight | |
| CNC machine tool | |
| Automatic feeding | |
| printer | |
| Feeder | |
| Wire cutting the workbench, | |
| Planting machine table (pores positioning) | |
| Packing machine | |
| ATM machine, | |
| Inkjet printer, | |
| Cutting plotter, | |
| Photo machine, | |
| Spraying equipment, | |
| Medical equipment and equipment, | |
| Computer peripherals and mass storage devices, | |
| precision instrument, | |
| Industrial control system, | |
| office automation, | |
| Robots and other fields. | |
| Computer embroidery machine, etc. |
|
Model 型号 |
Lead Wire 引出线 |
Length 机身长 |
Current 电流 |
Resistance 电阻 |
Inductance 电感 |
Max Static Torque 静转矩 |
Rotor Inertia 转子惯量 |
Weight 重量 |
| No. | mm | A | Ω | mH | kg.cm | g.com2 | KG | |
| 57BYGH41-01A | 4 | 41 | 2.0 | 1.2 | 2.5 | 0.6 | 150 | 0.47 |
| 57BYG56-01A | 2 | 56 | 0.8 | 0.9 | 2.5 | 1000 | 250 | 0.70 |
| 57BYG56-02A | 4 | 56 | 1 | 7.4 | 10 | 1000 | 250 | 0.70 |
| 57BYG56-03A | 4 | 56 | 2 | 1.8 | 2.5 | 1000 | 250 | 0.70 |
| 57BYG56-04A | 4 | 56 | 3 | 0.75 | 1.1 | 1000 | 250 | 0.70 |
| 57BYG56-05A | 4 | 56 | 1.5 | 3.1 | 5.5 | 0.9 | 440 | 0.59 |
| 57BYGH76-01A | 2 | 76 | 2.8 | 1.1 | 3.6 | 2000 | 440 | 1.00 |
| 57BYGH76-02A | 2 | 76 | 4 | 0.35 | 2.4 | 2000 | 440 | 1.00 |
| 57BYGH76-03A | 2 | 76 | 4.5 | 0.3 | 1.7 | 2000 | 440 | 1.00 |
| 57BYGH76-04A | 4 | 76 | 1 | 8.6 | 14 | 1600 | 440 | 1.00 |
| 57BYGH76-05A | 4 | 76 | 2 | 2.25 | 3.6 | 1600 | 440 | 1.00 |
| 57BYGH76-06A | 4 | 76 | 3 | 1 | 1.6 | 1600 | 440 | 1.00 |
| 57BYGH76-07A | 4 | 76 | 3.0 | 0.5 | 2.4 | 1.6 | 440 | 1.05 |
| 57BYGH84-01A | 4 | 84 | 3.0 | 0.6 | 2.5 | 2.0 | 530 | 1.13 |
| 57BYGH92-01A | 2 | 92 | 4 | 0.4 | 2.6 | 2200 | 680 | 1.2 |
| 57BYGH92-02A | 2 | 92 | 4.5 | 0.35 | 2 | 2200 | 680 | 1.2 |
| 57BYGH100-01A | 4 | 100 | 3.0 | 0.9 | 3.4 | 2.4 | 680 | 1.25 |
| 57BYGH102-01A | 2 | 102 | 4.5 | 0.4 | 2 | 2500 | 800 | 1.5 |
| 57BYGH112-01A | 4 | 112 | 3.0 | 1.6 | 6.8 | 2.5 | 800 | 1.40 |
