| NEMA 17(42MM) | |
| Product name | NEMA 17(42MM) |
| Steppermotor's Poles | 2 ; 4 |
| Frame Size | 42mm*42mm |
| Voltage | 2V - 16.3V |
| Max Static Torque | 1600-4400g.cm |
| Resistance | 0.83 -60 Ω |
| Cogging Torque | < 250-300 g.cm |
| Weight | 0.2kg-0.5kgs |
| Color | black |
| Application | Centrifugal machinery |
| Sewage treatment machine | |
| spotlight | |
| CNC machine tool | |
| Automatic feeding | |
| printer | |
| Feeder | |
| Wire cutting the workbench, | |
| Planting machine table (pores positioning) | |
| Packing machine | |
| ATM machine, | |
| Inkjet printer, | |
| Cutting plotter, | |
| Photo machine, | |
| Spraying equipment, | |
| Medical equipment and equipment, | |
| Computer peripherals and mass storage devices, | |
| precision instrument, | |
| Industrial control system, | |
| office automation, | |
| Robots and other fields. | |
| Computer embroidery machine, etc. |
|
Model 型号 |
Lead Wire 引出线 |
Length 机身长 |
Current 电流 |
Resistance 电阻 |
Inductance 电感 |
Max Static Torque 静转矩 |
Rotor Inertia 转子惯量 |
Weight 重量 |
| No. | mm | A | Ω | mH | kg.cm | g.com2 | KG | |
| 42BYGH20-01A | 4 | 20 | 0.8 | 3.8 | 4.5 | 10.0 | 24 | 0.12 |
| 42BYGH28-01A | 4 | 28 | 0.6 | 8.0 | 10.0 | 12.0 | 30 | 0.15 |
| 42BYGH34-01A | 2 | 34 | 1.3 | 2 | 2.3 | 2.6 | 25 | 0.20 |
| 42BYGH34-02A | 2 | 34 | 1.5 | 1.3 | 1.3 | 2.1 | 25 | 0.20 |
| 42BYGH34-03A | 2 | 34 | 0.4 | 30 | 33 | 2,8 | 25 | 0.20 |
| 42BYGH34-04A | 4 | 34 | 0.31 | 38.5 | 18 | 1.6 | 25 | 0.20 |
| 42BYGH34-05A | 4 | 34 | 1.7 | 1.2 | 1.8 | 28.0 | 34 | 0.22 |
| 42BYGH40-01A | 2 | 40 | 1.7 | 1.5 | 3.2 | 4.4 | 30 | 0.25 |
| 42BYGH40-02A | 2 | 40 | 0.87 | 3.3 | 5 | 2.4 | 30 | 0.25 |
| 42BYGH40-03A | 2 | 40 | 0.5 | 9 | 14 | 2.5 | 30 | 0.25 |
| 42BYGH40-04A | 2 | 40 | 0.6 | 5 | 8 | 2.5 | 30 | 0.25 |
| 42BYGH40-05A | 2 | 40 | 2.4 | 0.83 | 1.1 | 3.5 | 30 | 0.25 |
| 42BYGH40-06A | 2 | 40 | 0.28 | 60 | 80 | 3.2 | 30 | 0.25 |
| 42BYGH40-07A | 4 | 40 | 1.2 | 3 | 3.2 | 3.2 | 30 | 0.25 |
| 42BYGH40-08A | 4 | 40 | 0.4 | 30 | 25 | 2.8 | 30 | 0.25 |
| 42BYGH40-09A | 4 | 40 | 1.7 | 1.5 | 2.8 | 40.0 | 54 | 0.28 |
| 42BYGH48-01A | 4 | 48 | 1.7 | 1.8 | 3.2 | 52.0 | 68 | 0.35 |
| 42BYGH60-01A | 4 | 60 | 1.5 | 2.3 | 4.6 | 70.0 | 80 | 0.48 |
