| NEMA 16(39MM) | |
| Product name | NEMA 16(39MM) |
| Steppermotor's Wire | 4;6 |
| Frame Size | 39mm*39mm |
| Max Static Torque | 5-30N.cm |
| Resistance | 1-10Ω |
| Weight | 0.1-0.5kg |
| Color | black/ |
| Application | Spotlight |
| CNC machine tool | |
| 3D&Printer | |
| Wire cutting the workbench, | |
| Planting machine table (pores positioning) | |
| ATM machine, | |
| Inkjet printer, | |
| Cutting plotter, | |
| Photo machine, | |
| Medical equipment and equipment, | |
| Computer peripherals and mass storage devices, | |
| precision instrument, | |
| Office automation, | |
| Robots and other fields. | |
| Computer embroidery machine, etc. |
|
Model 型号 |
Lead Wire 引出线 |
Length 机身长 |
Current 电流 |
Resistance 电阻 |
Inductance 电感 |
Max Static Torque 静转矩 |
Rotor Inertia 转子惯量 |
Weigh 重量 |
| No. | mm | A | Ω | mH | N.cm | g.com2 | KG | |
| 39BYGH20-01A | 4 | 20 | 0.42 | 18 | 12 | 8 | 12 | 0.10 |
| 39BYGH26-01A | 4 | 26 | 0.6 | 9 | 10 | 14 | 14 | 0.12 |
| 39BYGH34-01A | 4 | 34 | 1.2 | 3.2 | 3 | 16 | 19 | 0.16 |
| 39BYGH34-02A | 6 | 34 | 0.4 | 30 | 14 | 12 | 19 | 0.16 |
| 39BYGH40-01A | 4 | 40 | 0.6 | 12 | 20 | 18 | 24 | 0.21 |
| 39BYGH40-02A | 4 | 40 | 1.2 | 3.8 | 6.5 | 24 | 24 | 0.21 |
