| NEMA 14(35MM) | |
| Product name | NEMA 14(35MM) |
| Steppermotor's Wire | 4 |
| Frame Size | 35mm*35mm |
| Max Static Torque | 1-20N.cm |
| Resistance | 1-30Ω |
| Cogging Torque | <150-220 g.cm |
| Weight | 0.1-0.2kgs |
| Color | black |
| Application | Spotlight |
| CNC machine tool | |
| 3D&Printer | |
| Wire cutting the workbench, | |
| Planting machine table (pores positioning) | |
| ATM machine, | |
| Inkjet printer, | |
| Cutting plotter, | |
| Photo machine, | |
| Medical equipment and equipment, | |
| Computer peripherals and mass storage devices, | |
| precision instrument, | |
| Office automation, | |
| Robots and other fields. | |
| Computer embroidery machine, etc. |
|
Model 型号 |
Lead Wire 引出线 |
Length 机身长 |
Current 电流 |
Resistance 电阻 |
Inductance 电感 |
Max Static Torque 静转矩 |
Rotor Inertia 转子惯量 |
Weight 重量 |
| No. | mm | A | Ω | mH | N.cm | g.com2 | KG | |
| 35BYGH20-01A | 4 | 20 | 0.4 | 22 | 16 | 5 | 9 | 0.09 |
| 35BYGH26-01A | 4 | 26 | 0.8 | 4.2 | 4.5 | 10 | 10 | 0.11 |
| 35BYGH28-01A | 4 | 28 | 0.8 | 5 | 5 | 12 | 11 | 0.12 |
| 35BYGH28-02A | 6 | 28 | 0.4 | 30 | 11 | 9 | 11 | 0.12 |
| 35BYGH34-01A | 4 | 34 | 0.8 | 6.5 | 9.8 | 18 | 13 | 0.16 |
| 35BYGH34-01A | 6 | 34 | 0.4 | 30 | 22 | 12 | 22 | 0.16 |
